8-ми контактный разъем TE | DEUTSCH | HDP20 Series | HDP24-18-8PN
8-ми контактный разъем TE | DEUTSCH | HDP20 Series | HDP24-18-8PN | Receptacle / Pin / Shell Size - 18 / Normal Wire Seal - Green Ring (Корпус)
8-ми контактный разъем TE | DEUTSCH | HDP20 Series | HDP24-18-8PN | Receptacle / Pin / Shell Size - 18 / Normal Wire Seal - Green Ring (Корпус)
Техническое описание:
- Connector Series - HDP20 Series
- Contact Series - Deutsch Series
- Connector Style - Receptacle
- Connector Material - PA 66 GF
- Number of Positions - 8
- Shell Size - 18
- Contact Type - Pin
- Contact Size - #12 x 8
- Contact Current Rating (Max) (A) - 25
- Wire Seal - N / Normal Position Wire Seal (Green Ring)
- Temperature rating: -55 °C to +125 °C
- Water protection - IP67
В комплект поставки входит:
- 8-ми контактный разъем TE | DEUTSCH | HDP20 Series | HDP24-18-8PN | Receptacle / Pin / Shell Size - 18 / Normal Wire Seal - Green Ring (Корпус) - 1 шт
Документация >>> TE | DEUTSCH | HDP24-18-8PN
Документация >>> TE | DEUTSCH | HDP20 Configurations
Документация >>> TE | DEUTSCH | HD30 Part Numbering System
