32-х контактный разъем TE | DEUTSCH | STRIKE Series | SRK13-MDA-32A-001

32-х контактный разъем TE | DEUTSCH | STRIKE Series | SRK13-MDA-32A-001 | PCB 90° Receptacle / Shell Size - MD / Keying Code - A / Contact Size - #16 #20 / Pin (Корпус)

Техническое описание:

• Connector Series - STRIKE Series
• Contact Series - Deutsch Series
• Connector Style - PCB
• PCB Mount Orientation - Right Angle / 90°
• Number of Positions - 32
• Contact Type - Pin
• Contact Size - #16 / #20
• Contact Current Rating (Max) (A) - #16 size - 13A / #20 - 7.5A
• Shell Size - MD / Medium

• Keying Kode - A
• Housing Material - PBT

• Temperature rating: -55 °C to +125 °C

В комплект поставки входит:

• 32-х контактный разъем TE | DEUTSCH | STRIKE Series | SRK13-MDA-32A-001 | PCB 90° Receptacle / Shell Size - MD / Keying Code - A / Contact Size - #16 #20 / Pin (Корпус) - 1 шт

Документация  >>>  TE | DEUTSCH | STRIKE Series | SRK13-MDA-32A-001

Документация  >>>  TE | DEUTSCH | STRIKE Series | Configurations

Документация  >>>  TE | DEUTSCH | STRIKE Series | Part Numbering System

Документация  >>>  TE | DEUTSCH | STRIKE Series | Technical Manual

Документация  >>>  TE | DEUTSCH | STRIKE Series | Product Drawings - 34 Way Connectors
